Erat series signatus Singulus/Tres Phase AC Filter Capacitor

Features:

Metallized polypropylene film magna perficientur

Aluminium cylindricum casu extrudendo obsignatum

Libitum siccum repletum, bonum anti-vibrationis effectus, nulla ultrices

Oleum libitum repletum, minus ponderis, et melius dissipationis caloris effectum

Humilis dissipatio factor, venae venae altae facultatem resistunt

Bene sanationis et intentionis sustinere

Disconnector pressio, tutior et certior

Operculum pulveris, seu incursu aleam terminals protecta

Cubits

Latin referenced	GB/T 17702（IEC61071），Libitum GB/T 12747（idt IEC 60831）
Aestimavit RMS Voltage	250Vac～1200Vac
Connection Type	Unum tempus, vel tria tempus cum Y vel Yn connexionis genus
Categoria climatica	40/85/56
Rated Frequency	50 vel 60 Hz
Overvoltage Umax	1.1 Urms: 8 h/d，1.15 Urms: 30 min/d，1.2 Urms: 5 min/d，
Overvoltage Umax	1.3 Urms: 1 min/d，1.5 Urms: 100 ms×1000 times
Capacitance Range	10μF～600μF
Facultas Tolerantia	± V% 、± X% vel aliis
Dielectrica Dissipatio Factor	0.0002
Voltage Test Inter Terminals	2.15 U _rms 1.5 U _N （50/60 Hz），10 s
Voltage test inter terminales et causam	4 000 Vac（50/60 Hz），10 s
Nulla resistentia	≥10000s（20 500 V，1 min）
Temperature Range operating	-40 85
Repono Temperature Range	-40 85
Maximum Altitude	2 000 m：（No derating for current.
Maximum Altitude	2000 m ad 4000 m：crescentium factor 3% per 500 m pro current
Expectata Vita	Arida type：100 000 h @ △C/C≤5% 0.8 U _rms , Θhs≤70 Oleum type：60 000 h @ △C/C≤5% U _rms , Θhs≤70
Expectata Vita
Modus refrigerandi	Naturaliter vel vi refrigeratum
salus	Proprietas sanationis sui et overpressure disconnector
Dielectric	Polypropylene pellicula
Casus	Aluminium extra cylindricum can
Terminals	Bolt：6N·m pro M8，8N·m pro M10（Dry type）；4N·m pro M8，6N·m pro M10（Oil type） Fibulae terminales：2N·m pro M5，3N·m pro M6
Terminals
Impregnation	Polyurethane vel oil

Dimensiones(mm)

	C _N (uF)	D (mm)	H (mm)	R _s (mΩ)	Ls (nH)	R _th* (K/W)	l _n	l _max	I (kA)	s (kA)	M (kg)
	C _N (uF)	D (mm)	H (mm)	R _s (mΩ)	Ls (nH)	R _th* (K/W)	l _n	l _max	I (kA)	s (kA)	M (kg)
U _rms =230Vac U _n =325Vac Us=700V	3×84	76	200	3×1.5	100	4.5	11	3×34	1.6	4.8	1.1
	3×105	76	230	3×1.6	120	4	13	3×36	1.5	4.5	1.2
	3×160	86	230	3×1.2	120	3.5	20	3×43	2.3	6.9	1.6
	3×250	116	200	3×0.8	110	3.1	31	3×53	3	9	2.4
	3×330	116	230	3×0.9	130	2.7	41	3×54	4.8	14.4	2.5
U _rms =440Vac U _n =625Vac Nobis = 300V	3×13	76	140	3×1.8	100	6.2	2	3×22	0.8	2.4	0.9
	3×16.5	76	140	3×1.5	100	5.6	2	3×25	1.1	3.3	0.9
	3×26.5	76	200	3×2.3	100	4.4	4	3×25	0.8	2.4	1.2
	3×33	76	200	3×1.9	100	4	5	3×28	1	3	1.2
	3×50	86	200	3×1.4	110	3.4	7	3×34	1.5	4.5	1.4
	3×66	86	230	3×1.5	120	2.9	9	3×36	1.4	4.2	1.7
	3×83	116	200	3×1.1	110	3.1	11	3×40	2.4	7.2	2.4
	3×100	116	200	3×1.0	110	2.8	14	3×43	2.9	8.7	2.4
	3×133	136	200	3×0.9	120	2.5	18	3×46	3.9	11.7	3.3
	3×154	136	200	3×0.8	120	2.3	21	3×48	4	12	3.3
	3×170	136	230	3×0.9	130	2.2	24	3×45	4.5	13.5	3.8
U _rms =540Vac U _n = 760Vac Nobis = 1600V	3×19	76	170	3×1.0	110	5.1	3	3×32	1	3	1
	3×23	76	170	3×1.0	110	5	4	3×33	1.2	3.6	1.2
	3×39	86	200	3×0.9	110	4	7	3×39	1.4	4.2	1.7
	3×48	86	230	3×1.0	120	3.6	8	3×40	1.3	3.9	1.9
	3×96	116	230	3×0.8	130	3	16	3×45	2.3	6.9	2.8
U _rms = 690Vac U _n =980Vac Us=2000V	3×33.5	116	170	3×0.8	110	3.5	7	3×42	1.6	4.8	2.2
	3×38	116	200	3×0.8	110	3.5	8	3×40	1.3	3.9	2.4
	3×75	136	230	3×0.8	130	2.6	16	3×45	1.9	5.7	3.7
U _rms =850Vac U _n = 200Vac Us=2550V	8	76	170	3×1.3	110	5.6	2	3×24	0.6	1.8	1
	10	86	170	3×1.1	110	5.2	3	3×27	0.7	2.1	1
	12	86	170	3×1.0	110	4.8	3	3×20	0.9	2.7	1
	17	106	170	3×0.9	110	4.3	5	3×34	1.1	3.3	1.7
	23	86	230	3×1.1	120	3.4	6	3×37	0.9	2.7	1.6
	28	106	230	3×1.0	130	3.3	7	3×38	1	3	2.2
	33	106	230	3×1.0	130	3	9	3×41	1.2	3.6	2.3
	38	116	230	3×0.9	130	2.9	10	3×42	1.4	4.2	2.8
	49	136	230	3×0.9	130	2.7	13	3×43	1.9	5.7	3.7
	55.8	136	230	3×0.8	130	2.5	15	3×45	2.2	6.6	3.8
